Torque spanner no. 721 Quick measuring range 40-200Nm output 1/2″ L. 483mm Wyjątkowa oferta

Opis

Opis:

• Made in Germany – STAHLWILLE tripping torque spanner, length 483 mm, with calibration certificate (DIN EN ISO 6789-2):2017), 50204020.
• Patented, low-wear release system with bending rod.
• Lightning-fast and precise torque adjustment.
• Continued loading after release or loading in the opposite direction of operation will not damage the torque spanner.

Features:

• Triggering with double stop signal
• No reset to ″0″ required
• the measuring element is only loaded during the tightening process
• Flash adjustment with easy-to-operate clamping lever in the handle
• Non-slip adjustment element with thumb recess for quick torque adjustment
• Double scale N-m/ft-lb
• Trigger mechanism insensitive to further and counter loads (max. up to the measuring range limit of the torque spanner)
• Calibration with the perfectControl® calibration devices no. 7791, no. 7794 or the calibration system no. 7706
• Simple adjustment from the outside using 2 adjustment screws without disassembly
• for the controlled right-hand suit
• with 2-component handle
• Calibration certificate according to DIN EN ISO 6789-2:2017
• Display deviation ± 4 %

Cecha szcz.:

• b1: 28 mm
• b2: 41 mm
• Output square external (inch): 1/2 inch
• Size: 20
• Height mm (h): 45 mm
• Height mm (h1): 23 mm
• Height mm (h2): 18 mm
• Length mm (L): 483 mm
• LF: 418 mm
• MA N-m: 40 N·m
• Measuring range ft-lb: 30-145 ft·lb
• Measuring range N-m: 40-200 N·m.
• Nominal value N-m: 200 N·m
• Scale division [E1]: 5 N·m
• Scale division [E2]: 5 ft-lb
• Weight: 1349g
• Width mm (b): 45 mm
