Opis
Najważniejsze parametry MUT-SET-T-SG-01 103055491
- Plug and play solution for muting applications
- Reduced mounting and wiring times
- Easy wiring with MCU-02 only one cable to the control cabinet
- One part number for all components
- Mounting to SG protective housing, MST mounting stand and sensor profile
- Muting set T-Version mounting at SG5/SG6, set complete with 4 muting sensors, MCU-02, mounting and cable
| Klucz zamówieniowy | |
|---|---|
| Oznaczenie typu produktu | MUT-SET-T-SG-01 |
| Numer artykułu (Numer katalogowy) | 103055491 |
| EAN (European Article Number) | 4030661645940 |
| Właściwości ogólne | |
| Wykonanie | T-Muting |
| Ciężar brutto | 2 800 g |
| Dane mechaniczne | |
| Montaż | Protective enclosure SG |
| Zakres dostawy | |
| Zakres dostawy | 4 x 103012847 MS-1200 – Mounting set for reflector R-D83,1 x 103005572 MCU-02 – Muting connection unit with cable connector for receiver M12/12pin, length 1,5m,1 x 101207729 KA-0905 – Connector cable from MCU-02 to control cabinet, M12/8-pin, L = 10,0 m,1 x 101214875 KA-0845 – Connector cable female for SLC/SLG445 transmitter on MCU-02, M12/4-pin, M12/4-pin, L = 5,0m,4 x 103040805 S100-PR – Muting sensor, retro-reflectiv sensor, dimension 32x20x12 mm, M8/4-pin,4 x 103055494 MS-ST-5039 – Mounting set for muting sensor S100-PR,2 x 103005657 KA-0846 – Cable for muting sensor, connector female M8, male M12, 4-pin L = 2,0 m,2 x 103005658 KA-0847 – Cable for muting sensor, connector female M8, male M12, 4-pin L = 5,0 m,4 x 101151760 RD 83 – Reflector, D = 83 mm,1 x 103055512 MS-MST-SG – Muting carrier set T-Version consists 4pcs of aluminium-profiles (20x20x400mm) fixed at SG with 2pcs U-brackets |
