Sound level meter – class I SW 1000 Dostępne od ręki

Opis

Opis:

• Ideal for measurements for workplaces outdoor, e.g. at airports, on building sites, in road construction etc. with broad access to spectrum thanks to the highly-accurate 24-Bit A/D converter
• Floating point evaluation for higher level of accuracy and better stability
• The optimised analogue frontend switch reduces the ambient noise and increases the linear measuring range
• A specially-developed algorithm permits a compliant dynamic range of more than 120 dB! (SW 1000: 123 dB, SW 2000: 122 dB)
• Three profiles and 14 user-defined measurements can be calculated in parallel with different frequency and time weighting
• LN statistics and display of the graph showing the progression of time
• User-defined integral interval measurement up to a maximum of 24 hours is possible
• Frequency weighting (filter) A, B, C, Z
• Time interval during measurement: F (fast), S (slow), I (pulse)
• Peak Hold Mode to capture peaks
• Octavo function for targeted sound analysis
• TRACK function with graphic display of a measurement
• Calibration mode (with optional calibrator)
• Trigger mode: external start/stop of measurement via 3.5 mm connector
• Automatic measurement for timer function is possible
• You can select the frequency for recording measurements: 10, 5, 2 Hz
• Operating languages: GB, DE, FR, ES, PT

Cecha szcz.:

• Applicable standards:IEC61672-1:2014-07GB/T3785.1–20101/1 Octavo in accordance with IEC 61260:2014
• ½ microphone
• Permissible ambient temperature -10 °C,-10 °C / 60 °C,60 °C
• Output (direct or alternating current) AC (max 5 VRMS), DC (10 mV/DB)
• Mains operation as standard
• Battery operation, 4x 1.5 V AA, as standard, operating time up to 10 h,10 h
• Overall dimensions W×D×H 300×80×36 mm,300×80×36 mm
• Net weight approx. 0,70 kg
