Opis:
- Particularly suitable for testing torque wrenches, electric hand screwdrivers and cordless screwdrivers
- AUTO-OFF function
- Can be used in both directions of rotation
- Data interface USB and RS-232 included
- LCD graphics display with backlight
- Sturdy mounting plate for secure fixing
- Measuring with tolerance range (function to set limits): Upper and lower limits can be programmed. The measurement process is supported by an audible and visual signal
- Metal housing for durable use in harsh environmental conditions
- Scope of delivery: Torque pick-up, sturdy carry case, mounting plate (models with [Max] ≥ 20 Nm)
- Internal data memory saves up to 500 measurements. The memory contents can be transferred to the PC using optional software
- Peak hold function to capture the peak value or Track function for continuous display of measurement
- Capacity display: A bar lights up to show how much of the measuring range is still available
Cecha szcz.:
- Internal measuring frequency: 1000 Hz
- Usable measuring range: 5 – 100 % of [Max]
- Overload protection: 120% of [Max]
- Net weight approx. 3,2 kg
- Internal rechargeable battery pack, as standard, operating time up to 18 h without back light, charging time approx. 14 h
- Overall dimensions W×D×H 200×100×50 mm
- Selectable measuring units: Nm, lbf-in, kgf-cm, kgf-m, ft-lbf
- Measuring precision: ± 0,5% of [Max]
- Internal measuring frequency: 1000 Hz
- Usable measuring range: 5 – 100 % of [Max]
- Overload protection: 120% of [Max]
- Net weight approx. 3,2 kg
- Internal rechargeable battery pack, as standard, operating time up to 18 h without back light, charging time approx. 14 h
- Overall dimensions W×D×H 200×100×50 mm
- Selectable measuring units: Nm, lbf-in, kgf-cm, kgf-m, ft-lbf
- Measuring precision: ± 0,5% of [Max]
