Opis
Opis:
Application:
Operation of cardan shaft screw connection on VW Golf model year 2004 →, Touran model year 2004 →, Golf Plus model year 2006 →, Eos model year 2006 →, Scirocco model year 2009 →, Tiguan model year 2008 →, AUDI A3 model year 2004 →, TT model year 2007 →
- With borehole for locking pin or safety spring and grove for O-ring
- Surface: phosphatized, oiled
- DIN 3129, ISO 2725-2
- Made in Germany
- Drive: Square, hollow 12.5 mm (1/2 inch)
- Output: Outside 12-point traction profile
- Wrench size: 24 mm
- Dimensions / length: 44 mm
- Diameter d1 (output side): 35 mm
- Diameter d2 (drive side): 30 mm
- Net weight: 0.17 kg
- For impact operation
